Automatization of the pipeline

Picture of the fretwork on the ruins in Mitla, Oaxaca.

Extracting the tax-id number

Around the chapters, I have been creating a pipeline that can take the SRA data to download the data, do the taxonomic identification with kraken2, create the biom files, and extract Clavibacter reads. But what about doing the same set of steps for a different genus?

As I explained before, what we need to extract the specific reads of a specific lineage I need the tax-id number from NCBI. For the genus CLavibacter it was the 1573.

First, I will search for a file where the information for all the NCBI taxonomic information is allocated inside the NCBI-taxonomy page. There are a lot of options, but I will use the files that are inside new_taxdump. Specifically I will use the file names.dmp because all the OTUs are sorted in tax-id ascendent order:

$ head -n20 names.dmp

1       |       all     |               |       synonym |
1       |       root    |               |       scientific name |
2       |       Bacteria        |       Bacteria <bacteria>     |       scientific name |
2       |       bacteria        |               |       blast name      |
2       |       eubacteria      |               |       genbank common name     |
2       |       Monera  |       Monera <bacteria>       |       in-part |
2       |       Procaryotae     |       Procaryotae <bacteria>  |       in-part |
2       |       Prokaryotae     |       Prokaryotae <bacteria>  |       in-part |
2       |       Prokaryota      |       Prokaryota <bacteria>   |       in-part |
2       |       prokaryote      |       prokaryote <bacteria>   |       in-part |
2       |       prokaryotes     |       prokaryotes <bacteria>  |       in-part |
6       |       Azorhizobium Dreyfus et al. 1988 emend. Lang et al. 2013        |               |    authority        |
6       |       Azorhizobium    |               |       scientific name |
7       |       Azorhizobium caulinodans Dreyfus et al. 1988    |               |       authority    |
7       |       Azorhizobium caulinodans        |               |       scientific name |
7       |       Azotirhizobium caulinodans      |               |       equivalent name |
9       |       Acyrthosiphon pisum symbiont P  |               |       includes        |
9       |       Buchnera aphidicola Munson et al. 1991  |               |       authority       |
9       |       Buchnera aphidicola     |               |       scientific name |
9       |       primary endosymbiont of Schizaphis graminum     |               |       includes     |

Next, I need a way to extract the tax-id number at the genus level. Since each character string is separated by a tab separators, I will use this feature to extract the genus specific line of Nostoc:

$ grep "$(printf '\t')Nostoc$(printf '\t')" names.dmp

1177    |       Nostoc  |               |       scientific name |

That is a great output, now I want to obtain just the first numbers:

$ grep "$(printf '\t')Nostoc$(printf '\t')" names.dmp |  grep -o '[0-9]*'

1177

The all-around pipeline

Until now, the all-around.sh program have the next lines of code:

#!/bin/sh
# This is a program that is going to pick a SraRunTable of metadata and
#extract the run label to download, trim and move the libraries information.

# This program requires that you give 4 input data: 1) where this
#SraRunTable is located, 2) where the kraken database has been saved,
# 3) the name of the author of the library, and 4) A prefix for some of the
# output files, in this case the name of the plant's host.

#ASSIGNATIONS
metd=$1 #Location to the SraRunTable.txt
kdat=$2 #Location of the kraken2 database
aut=$3 #A first prefix to name some of the files. In this case, the author name.
pref=$4 #The second prefix. In this case the name of the plant's host

root=$(pwd) #Gets the path to the directory of this file, on which the outputs ought to be created
# Now we will define were the reads are:
runs='reads'

# CREATING NECCESARY FOLDERS
mkdir reads
mkdir -p taxonomy/kraken
mkdir -p taxonomy/taxonomy-logs/scripts
mkdir -p taxonomy/kraken/reports
mkdir -p taxonomy/kraken/krakens
mkdir -p taxonomy/biom-files

mkdir -p reads/clavi/
mkdir -p reads/cmm/
mkdir -p reads/fasta-clavi

# DOWNLOADING THE DATA

#Let's use the next piece of code to download the data
cat $metd  |  sed -n '1!p' | while read line;  do read=$(echo $line | cut -d',' -f1); fasterq-dump -S $read -p -e 8 -o $read ; done
mv *.fastq reads/
# The -e flag can be customized. This indicates the number of threads used to do this task.

# MANAGING THE DOWNLADED DATA

# We will change the names of the reads files. They have a sufix that makes impossible
#to be read in a loop
ls $runs | while read line ; do new=$(echo $line | sed 's/_/-/g'); mv $runs/$line $runs/$new; done

# Now, we will create a file where the information of the run labes can be located
cat $metd  | sed -n '1!p' | while read line; do read=$(echo $line | cut -d',' -f1); echo $read ; done > run-labels.txt
mv run-labels.txt metadata/

# TAXONOMIC ASSIGNATION WITH KRAKEN2

cat metadata/run-labels.txt | while read line; do file1=$(echo $runs/$line-1.fastq); file2=$(echo $runs/$line-2.fastq) ; echo '\n''working in run' "$line"\
#kraken2 --db $kdat --threads 6 --paired $file1 $file2 --output taxonomy/kraken/krakens/$line.kraken --report taxonomy/kraken/reports/$line.report \
echo '#!/bin/sh''\n''\n'"kraken2 --db $kdat --threads 6 --paired" "$runs/$line"'-1.fastq' "$runs/$line"'-2.fastq' "--output taxonomy/kraken/krakens/$line.kraken --report taxonomy/kraken/reports/$line.report" > taxonomy/taxonomy-logs/scripts/$line-kraken.sh; sh taxonomy/taxonomy-logs/scripts/$line-kraken.sh; done

#CREATING THE BIOM FILE

# Now we will create the biom file using kraken-biom
kraken-biom taxonomy/kraken/reports/* --fmt json -o taxonomy/biom-files/$aut.biom

# EXTRACTING THE CLAVIBACTER READS
# With the next piece of code, the reads clasiffied as from the genus "Clavibacter", will be separated from the main reads.
# The number needed for the extraction is the numeric-ID given to Clavibacter by kraken2: 1573

#EXTRACT THE READS IN FASTQ FORMAT
cat metadata/run-labels.txt | while read line;
do echo "\nExtracting Clavibacter reads in fastq from sample:" $line;
extract_kraken_reads.py -k taxonomy/kraken/krakens/$line.kraken -r taxonomy/kraken/reports/$line.report -s1 reads/$line-1.fastq -s2 reads/$line-2.fastq -o reads/clavi/$pref-$aut-$line-clav-1.fq -o2 reads/clavi/$pref-$aut-$line-clav-2.fq -t 1573 --fastq-output --include-children; done

#EXTRACT THE READS IN FASTA FORMAT
cat metadata/run-labels.txt | while read line;
do echo "\nExtracting Clavibacter reads in fasta from sample:" $line;
extract_kraken_reads.py -k taxonomy/kraken/krakens/$line.kraken -r taxonomy/kraken/reports/$line.report -s1 reads/$line-1.fastq -s2 reads/$line-2.fastq -o reads/fasta-clavi/$pref-$aut-$line-clav-1.fasta -o2 reads/fasta-clavi/$pref-$aut-$line-clav-2.fasta -t 1573 --include-children; done

# EXTRACTING THE CLAVIBACTER MICHIGANESIS-MICHIGANENSIS READS
# With the next piece of code, the reads clasiffied as from the Clavibacter michiganensis michiganensis, will be separated from the main reads.
# The number needed for the extraction is the numeric-ID given to Cmm by kraken2: 33013

cat metadata/run-labels.txt | while read line;
do echo "\nExtracting Cmm reads in fasta format from sample:" $line; extract_kraken_reads.py -k taxonomy/kraken/krakens/$line.kraken -r taxonomy/kraken/reports/$line.report -s1 reads/$line-1.fastq -s2 reads/$line-2.fastq -o reads/cmm/cmm-$pref-$aut-$line-1.fasta -o2 reads/cmm/cmm-$pref-$aut-$line-2.fasta -t 33013 --include-children; done

I am going to modify it to ask for a new input: The genus of interest. I also will modify this to use this tax-id to extract the reads from this genus.

The new input lines will be as follows:

ndmp=$5 #Location of the "names.dmp" file
igen=$6 #Genus of interest

And the original last 15 lines of all-around.sh, will change for the next piece of code:

# OBTAINING THE TAX-ID NUMBER FROM THE "names.dmp" FILE
taxid=$(grep "$(printf '\t')$igen$(printf '\t')" $ndmp | grep -o '[0-9]*')

# Putting this information in a file:
grep "$(printf '\t')$igen$(printf '\t')" $ndmp | while read line;
do tid=$(echo $line | cut -d' ' -f1); oname=$(echo $line | cut -d' ' -f3);
echo "Genus""\t""tax-id" > taxonomy/genus-interest.txt;
echo $oname"\t"$tid >> taxonomy/genus-interest.txt;
done

# EXTRACTING THE READS FROM THE GENUS OF INTEREST
# With the next piece of code, the reads clasiffied as the Genus of interest, will be separated from the main reads.

#EXTRACT THE READS IN FASTQ FORMAT
cat metadata/run-labels.txt | while read line;
do echo "\n"Extracting $igen reads in fastq from sample: $line;
extract_kraken_reads.py -k taxonomy/kraken/krakens/$line.kraken -r taxonomy/kraken/reports/$line.report -s1 reads/$line-1.fastq -s2 reads/$line-2.fastq -o reads/$igen/$pref-$aut-$igen-$line-1.fq -o2 reads/$igen/$pref-$aut-$igen-$line-2.fq -t $taxid --fastq-output --include-children; done

#EXTRACT THE READS IN FASTA FORMAT
cat metadata/run-labels.txt | while read line;
do echo "\n"Extracting $igen reads in fasta from sample: $line;
extract_kraken_reads.py -k taxonomy/kraken/krakens/$line.kraken -r taxonomy/kraken/reports/$line.report -s1 reads/$line-1.fastq -s2 reads/$line-2.fastq -o reads/fasta-$igen/$pref-$aut-$igen-$line-1.fasta -o2 reads/fasta-$igen/$pref-$aut-$igen-$line-2.fasta -t $taxid --include-children; done

This program will generate an output file genus-interest.txt inside the taxonomy/ folder.

In the end, we will have a new scrit that we will call iall-around.sh because of the little interactivity of enabling the user to choose the genus of interest:

#!/bin/sh
# This is a program that is going to pick a SraRunTable of metadata and
#extract the run label to download, trim and move the libraries information.
# It gives the user the option to extract the reads from a specific genus
# of bacterial lineages.

# REQUIREMENTS:
#a) A kraken2 database in a known location
#b) The "names.dmp" file from NCBI: https://ftp.ncbi.nlm.nih.gov/pub/taxonomy/new_taxdump/
#c) The SraRunTable of the experiments of insterest

# This program requires that you give 6 input data:
#1) where the SraRunTable is located
#2) where the kraken database has been assembled
#3) the name of the author of the library
#4) A prefix for some of the output files, in this case the name of the plant's host.
#5) The localization of the "names.dmp" file
#6) The genus name of interest. This is for the extraction of this genus reads from the different libraries to analize.

#ASSIGNATIONS
metd=$1 #Location to the SraRunTable.txt
kdat=$2 #Location of the kraken2 database
aut=$3 #A first prefix to name some of the files. In this case, the author name.
pref=$4 #The second prefix. In this case the name of the plant's host
ndmp=$5 #Location of the "names.dmp" file
igen=$6 #Genus of interest

root=$(pwd) #Gets the path to the directory of this file, on which the outputs ought to be created
# Now we will define were the reads are:
runs='reads'

# CREATING NECCESARY FOLDERS
mkdir reads
mkdir -p taxonomy/kraken
mkdir -p taxonomy/taxonomy-logs/scripts
mkdir -p taxonomy/kraken/reports
mkdir -p taxonomy/kraken/krakens
mkdir -p taxonomy/biom-files

mkdir -p reads/$igen
mkdir -p reads/fasta-$igen

# DOWNLOADING THE DATA

#Let's use the next piece of code to download the data
cat $metd  |  sed -n '1!p' | while read line;  do read=$(echo $line | cut -d',' -f1); fasterq-dump -S $read -p -e 8 -o $read ; done
mv *.fastq reads/
# The -e flag can be customized. This indicates the number of threads used to do this task.

# MANAGING THE DOWNLADED DATA

# We will change the names of the reads files. They have a sufix that makes impossible
#to be read in a loop
ls $runs | while read line ; do new=$(echo $line | sed 's/_/-/g'); mv $runs/$line $runs/$new; done

# Now, we will create a file where the information of the run labes can be located
cat $metd  | sed -n '1!p' | while read line; do read=$(echo $line | cut -d',' -f1); echo $read ; done > run-labels.txt
mv run-labels.txt metadata/

# TAXONOMIC ASSIGNATION WITH KRAKEN2

cat metadata/run-labels.txt | while read line; do file1=$(echo $runs/$line-1.fastq); file2=$(echo $runs/$line-2.fastq) ; echo '\n''working in run' "$line"\
#kraken2 --db $kdat --threads 6 --paired $file1 $file2 --output taxonomy/kraken/krakens/$line.kraken --report taxonomy/kraken/reports/$line.report \
echo '#!/bin/sh''\n''\n'"kraken2 --db $kdat --threads 6 --paired" "$runs/$line"'-1.fastq' "$runs/$line"'-2.fastq' "--output taxonomy/kraken/krakens/$line.kraken --report taxonomy/kraken/reports/$line.report" > taxonomy/taxonomy-logs/scripts/$line-kraken.sh; sh taxonomy/taxonomy-logs/scripts/$line-kraken.sh; done

#CREATING THE BIOM FILE

# Now we will create the biom file using kraken-biom
kraken-biom taxonomy/kraken/reports/* --fmt json -o taxonomy/biom-files/$aut.biom

# OBTAINING THE TAX-ID NUMBER FROM THE "names.dmp" FILE
taxid=$(grep "$(printf '\t')$igen$(printf '\t')" $ndmp | grep -o '[0-9]*')

# Putting this information in a file:
grep "$(printf '\t')$igen$(printf '\t')" $ndmp | while read line;
do tid=$(echo $line | cut -d' ' -f1); oname=$(echo $line | cut -d' ' -f3);
echo "Genus""\t""tax-id" > taxonomy/genus-interest.txt;
echo $oname"\t"$tid >> taxonomy/genus-interest.txt;
done

# EXTRACTING THE READS FROM THE GENUS OF INTEREST
# With the next piece of code, the reads clasiffied as the Genus of interest, will be separated from the main reads.

#EXTRACT THE READS IN FASTQ FORMAT
cat metadata/run-labels.txt | while read line;
do echo "\n"Extracting $igen reads in fastq from sample: $line;
extract_kraken_reads.py -k taxonomy/kraken/krakens/$line.kraken -r taxonomy/kraken/reports/$line.report -s1 reads/$line-1.fastq -s2 reads/$line-2.fastq -o reads/$igen/$pref-$aut-$igen-$line-1.fq -o2 reads/$igen/$pref-$aut-$igen-$line-2.fq -t $taxid --fastq-output --include-children; done

#EXTRACT THE READS IN FASTA FORMAT
cat metadata/run-labels.txt | while read line;
do echo "\n"Extracting $igen reads in fasta from sample: $line;
extract_kraken_reads.py -k taxonomy/kraken/krakens/$line.kraken -r taxonomy/kraken/reports/$line.report -s1 reads/$line-1.fastq -s2 reads/$line-2.fastq -o reads/fasta-$igen/$pref-$aut-$igen-$line-1.fasta -o2 reads/fasta-$igen/$pref-$aut-$igen-$line-2.fasta -t $taxid --include-children; done

As all the other scripts, this will be located in the scripts folder of the repository.
