clavibacter
Taxonomic assignation with kraken2
Preparing the database
For the taxonomic assigantion I will going to use kraken2. The algorith that this software use has demostrated to be accurate and reliable.
According to the kraken2 manual, it is imperative that first we assemble a databese. I downloaded the next set of databases because I want to have the capability to discern if the the source of the reads that we are obtaining:
- Archea
- Bacteria
- Fungi
- Viral
The database at the end occupies close to 209 Gb of disk space and needs at least 58 Gb of RAM memory to be able to do the taxonomic assignation. I put the information of the database in a location I can easily remember because I will need to write the directory’s location in during the next steps:
$ pwd
/mnt/d/programs/kraken/database
I run the next set lines of code to assemble the databese. First, I downloaded each set of information of the four groups I mentioned before:
$ kraken2-build --download-library archaea --db datab03242022
$ kraken2-build --download-library bacteria --db datab03242022
$ kraken2-build --download-library fungi --db datab03242022
$ kraken2-build --download-library viral --db datab03242022
I named the database with the date it was assembled to have a record of this and be aware when it is convenient to update it. Secondly, I downloaded the taxonomy information:
$ kraken2-build --download-taxonomy --db datab03242022
Finally, I build the database:
$ kraken2-build --build --db datab03242022
All this process took my hardware (SSD, 64 RAM memory, 16 cores) close to 36 hours.
Running kraken2
With the database already created, we can return to the directory where we have the information from Choi-2020.
First, we will create a set of folders where we can save all the outputs that we will obtain from kraken:
$ mkdir -p taxonomy/kraken/reports
$ mkdir -p taxonomy/kraken/krakens
We will use the next line to run the kraken2 algorith with, using the “recently”
created database:
$ kraken2 --db /mnt/d/programs/kraken/database/database/datab03242022 --threads 8 --paired reads/SRR12778013-1.fastq reads/SRR12778013-2.fastq --output taxonomy/kraken/krakens/SRR12778013.kraken --report taxonomy/kraken/krakens/SRR12778013.report
reads/SRR12778013-1.fastq reads/SRR12778013-2.fastq
Loading database information... done.
60417 sequences (29.85 Mbp) processed in 3.700s (979.6 Kseq/m, 483.93 Mbp/m).
60403 sequences classified (99.98%)
14 sequences unclassified (0.02%)
Now, we have our first result from the first library:
$ head -n 15 taxonomy/kraken/reports/SRR12778013.report
95.30 65820224 65820224 U 0 unclassified
4.70 3245750 10996 R 1 root
4.50 3104957 55642 R1 131567 cellular organisms
2.37 1638696 0 D 2759 Eukaryota
2.37 1638693 0 D1 33154 Opisthokonta
2.37 1638693 0 K 33208 Metazoa
2.37 1638693 0 K1 6072 Eumetazoa
2.37 1638693 0 K2 33213 Bilateria
2.37 1638693 0 K3 33511 Deuterostomia
2.37 1638693 0 P 7711 Chordata
2.37 1638693 0 P1 89593 Craniata
2.37 1638693 0 P2 7742 Vertebrata
2.37 1638693 0 P3 7776 Gnathostomata
2.37 1638693 0 P4 117570 Teleostomi
2.37 1638693 0 P5 117571 Euteleostomi
Continue with the program construction
As I began on the last episode, I will update the all-around program with this
new step of running the kraken2 in all the files that we have. The program has the name kraken-reads.sh and can be located inside the scripts folder of this repository.
Let’s see what is new inside:
$ cat kraken-reads.sh
#!/bin/sh
# This is a program that is going to pick a SraRunTable of metadata and
#extract the run label to download, trim and move the libraries information.
# This program requires that you give 2 input data: 1) where this
#SraRunTable is located, and 2) where the kraken database has been saved
#ASSIGNATIONS
metd=$1 #Location to the SraRunTable.txt
kdat=$2 #Location of the kraken2 database
root=$(pwd) #Gets the path to the directory of this file, on which the outputs ought to be created
# Now we will define were the reads are:
runs='reads'
# CREATING NECCESARY FOLDERS
mkdir reads
mkdir -p taxonomy/kraken
mkdir -p taxonomy/taxonomy-logs/scripts
mkdir -p taxonomy/kraken/reports
mkdir -p taxonomy/kraken/krakens
# DOWNLOADING THE DATA
#Let's use the next piece of code to download the data
cat $metd | sed -n '1!p' | while read line; do read=$(echo $line | cut -d',' -f1); fasterq-dump -S $read -p -e 8 -o $read ; done
mv *.fastq reads/
# The -e flag can be customized. This indicates the number of threads used to do this task.
# MANAGING THE DOWNLADED DATA
# We will change the names of the reads files. They have a sufix that makes impossible
#to be read in a loop
ls $runs | while read line ; do new=$(echo $line | sed 's/_/-/g'); mv $runs/$line $runs/$new; done
# Now, we will create a file where the information of the run labes can be located
cat $metd | sed -n '1!p' | while read line; do read=$(echo $line | cut -d',' -f1); echo $read ; done > run-labels.txt
mv run-labels.txt metadata/
# TAXONOMIC ASSIGNATION WITH KRAKEN2
cat metadata/run-labels.txt | while read line; do file1=$(echo $runs/$line-1.fastq); file2=$(echo $runs/$line-2.fastq) ; echo '\n''working in run' "$line"\
#kraken2 --db $kdat --threads 6 --paired $file1 $file2 --output taxonomy/kraken/krakens/$line.kraken --report taxonomy/kraken/reports/$line.report \
echo '#!/bin/sh''\n''\n'"kraken2 --db $kdat --threads 6 --paired" "$runs/$line"'-1.fastq' "$runs/$line"'-2.fastq' "--output taxonomy/kraken/krakens/$line.kraken --report taxonomy/kraken/reports/$line.report" > taxonomy/taxonomy-logs/scripts/$line-kraken.sh; sh taxonomy/taxonomy-logs/scripts/$line-kraken.sh; done
As it says in the first lines, now you will need to provide it with 1) the location of your SraRunTable.txt file, and 2) the location of your kraken2 database. This program will create in your actual directory the folders where the outputs are going to be allocated and little pieces of code in the taxonomy-logs/scripts folder that were used to run kraken2 on each
pair of reads.
The 26th line is commented because I could not made kraken2 to run inside the while loop. If you can find any solutions or any improvements, please let me know.
(diego.garfias@cinvestav.mx)
You can always change the number of threads to be used.
So, in my case I am going to run it with the following command:
$ sh kraken-reads.sh metadata/SraRunTable.txt /mnt/d/programs/kraken/database/database/datab03242022
working in run SRR12778013
reads/SRR12778013-1.fastq reads/SRR12778013-2.fastq
Loading database information... done.
60417 sequences (29.85 Mbp) processed in 3.700s (979.6 Kseq/m, 483.93 Mbp/m).
60403 sequences classified (99.98%)
14 sequences unclassified (0.02%)
working in run SRR12778014
reads/SRR12778014-1.fastq reads/SRR12778014-2.fastq
Loading database information... done.
68119 sequences (33.72 Mbp) processed in 3.412s (1197.9 Kseq/m, 592.97 Mbp/m).
68109 sequences classified (99.99%)
10 sequences unclassified (0.01%)
The resulting output is telling us that kraken2 is running on the files that
we gave to the program. It will take a several minutes to a couple of hours to
process this set of 24 samples.
By the end of the process, we will have a new set of content inside the taxonomy/ folder. Let’s see what it is inside.
$ tree -L 2
.
├── kraken
│ ├── krakens
│ │ ├── SRR12778013.kraken
│ │ ├── SRR12778014.kraken
│ │ ├── SRR12778015.kraken
│ │ ├── SRR12778016.kraken
│ │ ├── SRR12778017.kraken
│ │ ├── SRR12778018.kraken
│ │ ├── SRR12778019.kraken
│ │ ├── SRR12778020.kraken
│ │ ├── SRR12778021.kraken
│ │ ├── SRR12778022.kraken
│ │ ├── SRR12778023.kraken
│ │ └── SRR12778024.kraken
│ └── reports
│ ├── SRR12778013.report
│ ├── SRR12778014.report
│ ├── SRR12778015.report
│ ├── SRR12778016.report
│ ├── SRR12778017.report
│ ├── SRR12778018.report
│ ├── SRR12778019.report
│ ├── SRR12778020.report
│ ├── SRR12778021.report
│ ├── SRR12778022.report
│ ├── SRR12778023.report
│ └── SRR12778024.report
└── taxonomy-logs
└── scripts
├── SRR12778013-kraken.sh
├── SRR12778014-kraken.sh
├── SRR12778015-kraken.sh
├── SRR12778016-kraken.sh
├── SRR12778017-kraken.sh
├── SRR12778018-kraken.sh
├── SRR12778019-kraken.sh
├── SRR12778020-kraken.sh
├── SRR12778021-kraken.sh
├── SRR12778022-kraken.sh
├── SRR12778023-kraken.sh
└── SRR12778024-kraken.sh
6 directories, 36 files
Inside the reports/ folder are all the reports from all the samples that the
script processed. The same goes for the krakens/ folder
Now, we can do this same process with each of the capsicum folders. Inside miscelaneous-capsicum and newberry-2020 folders, I will use the next line of code to obtain the desired results:
$ sh kraken-reads.sh metadata/SraRunTable.txt /mnt/d/programs/kraken/database/database/datab03242022
If we expore what we obtained, we will see the results are there:
$ for i in miscelaneous-capsicum newberry-2020; do echo -e "\n"; tree $i -L 3; done
miscelaneous-capsicum
├── kraken-reads.sh
├── metadata
│ ├── run-labels.txt
│ ├── SraRunTable.txt
│ └── SRR_Acc_List.txt
├── reads
│ ├── ERR5639101-1.fastq
│ ├── ERR5639101-2.fastq
│ ├── SRR13319509-1.fastq
│ ├── SRR13319509-2.fastq
│ ├── SRR13319510-1.fastq
│ ├── SRR13319510-2.fastq
│ ├── SRR13319511-1.fastq
│ └── SRR13319511-2.fastq
└── taxonomy
├── kraken
│ ├── krakens
│ └── reports
└── taxonomy-logs
└── scripts
8 directories, 12 files
newberry-2020
├── kraken-reads.sh
├── metadata
│ ├── run-labels.txt
│ ├── SraRunTable.txt
│ └── SRR_Acc_List.txt
├── reads
│ ├── SRR10527387-1.fastq
│ ├── SRR10527387-2.fastq
│ ├── SRR10527388-1.fastq
│ ├── SRR10527388-2.fastq
│ ├── SRR10527389-1.fastq
│ └── SRR10527389-2.fastq
└── taxonomy
├── kraken
│ ├── krakens
│ └── reports
└── taxonomy-logs
└── scripts
8 directories, 10 files
With this, we can progress to do the same for all the set of libraries that we want
to process with kraken2
